Phantom Flex 4k
The Phantom Flex 4K is a high-speed digital cinema camera known for its exceptional frame rates and image quality. It features a Super 35mm CMOS sensor, offering 4K resolution at up to 1,000 fps and nearly 2,000 fps at 2K. The camera has an exposure index range of 200 to 1,250 for optimal performance in various lighting conditions.
Designed for professional cinematography, the Flex 4K supports PL and EF lens mounts and offers 12-bit color depth. It records in formats like Cine RAW and Apple ProRes 422 HQ, making it ideal for feature films, high-end commercials, and seamless post-production workflows.
Model
Flex 4K
Sensor
CMOS Sensor (27.6 mm x 15.5 mm)
Super 35mm -31.7 mm ø
Lens Mount
Recording Format
File Format
| ARRIRAW | MXF |
| ProRes | MXF |
Resolution
| ARRIRAW LF 16:9 4K UHD | 3840×2160 |
| ARRIRAW LF 2.31:1 Scope 4.5K | 4480×1856 |
| ARRIRAW LF Open Gate 4.5K | 4448×3096 |
| ProRes LF 16:9 4K UHD | 3840×2160 |
| ProRes LF 16:9 2K | 2048×1152 |
| ProRes LF 16:9 HD | 1920×1080 |
| ProRes LF 2.31:1 Scope 4.5K | 4480×1856 |
| ProRes LF Open Gate 4.5K | 4448×3096 |
Maximum Frame Rate (PAL)
| ARRIRAW LF 16:9 4K UHD | 60 fps |
| ARRIRAW LF 2.31:1 Scope 4.5K | 60 fps |
| ARRIRAW LF Open Gate 4.5K | 40 fps |
| ProRes LF 16:9 4K UHD | 60 fps |
| ProRes LF 16:9 2K | 90 fps |
| ProRes LF 16:9 HD | 90 fps |
| ProRes LF 2.31:1 Scope 4.5K | 60 fps |
| ProRes LF Open Gate 4.5K | 40 fps |
Media
| Internal Recording | Compact Drive |
| Setup | USB |
Audio Recording Format
MXF: 2-Channel 24-Bit 48 kHz LPCM Audio
Exposure Index (EI)
| EI Range | 160-3200 ASA |
| Native EI | 800 ASA |
Internal ND Filters
Batteries
V-Lock Plate
Inputs
1 x 6-Pin LEMO Input
1 x 5-Pin LEMO Timecode Data
1 x 10-Pin LEMO LAN Data, Control
1 x BNC Sync Control
1 x 7-Pin LEMO Monitor
1 x USB Type-A USB 2.0 Data
1 x Proprietary Viewfinder
1 x 8-Pin LEMO (10.5 to 34 VDC)
Outputs
2x BNC (6G-SDI Out)
1 x 5-Pin LEMO Timecode Data
1 x 10-Pin LEMO LAN Data, Control
1 x BNC Sync Control
1 x 7-Pin LEMO Monitor
1 x USB Type-A USB 2.0 Data
1 x Proprietary Viewfinder
1 x 3-Pin RS (24 VDC)
1 x 2-Pin LEMO (12 VDC)
1 x Proprietary (24 VDC)
Power Consumption
≥65 W
Weight
lb /
kg (body & PL Mount only)
