Load Capacity
13.6 kgs
Weight
5.5 kgs
Camera Requirements
| Max depth from centre of gravity on base plate | 245mm |
| Max height from top of base plate | 165mm |
| Max width | 180mm |
Maximum Controlled Rotational Speed
| Pan Axis Control | 400°/s |
| Tilt Axis Control | 360°/s |
| Roll Axis Control | 360°/s |
Controlled Rotational Range
| Pan Axis Control | 360° |
| Tilt Axis Control | +45° to -135° |
| Roll Axis Control | +45° to -45° |
Mechanical Endpoint Range
| Pan Axis Control | 360° |
| Tilt Axis Control | +135° to -135° |
| Roll Axis Control | +220° to -220° |
Operation Modes
Underslung Mode
Upright Mode
Briefcase Mode
Handheld, Car Mount, Aerial, Tripod & Steadicam Mode
