Canon C700 Full-Frame EF/PL

$1 per day

The Canon C700 Full-Frame Cinema Camera features a newly developed 5.9K sensor which captures to CFast cards in both XF-AVC and ProRes, with frame rates up to 50 fps in 5.9K.

Downloadable Specs coming soon….



Model

Canon C700 Full-Frame

Sensor

5.9K Full-Frame CMOS Sensor with DAF

Lens Mount

PL / EF

Recording Format

XF-AVC 10-bit 4:2:2 YCC

XF-AVC 10/12-bit 4:4:4:4 RGB

XF-AVC 8-bit 4:2:0 YCC (proxy)

ProRes 10-bit 4:2:2 YCC

ProRes 12-bit 4:4:4:4 RGB

File Format

XF-AVC MXF
ProRes MOV
Raw RMF

*RAW via a Codex Drive or SDI. SDI limited to 50P at 4096×2160 10-bit

Internal Recording Resolution

4K 4096×2160
UHD 3840×2160
2K 2048×1080
HD 1920×1080

*Approx. 18.69 megapixels (5952 x 3140): When 4096 x 2160 or 2048 x 1080 is selected as the resolution

* Approx. 17.52 megapixels (5580 x 3140): When 3840 x 2160 or 1920 x 1080 is selected as the resolution

External Recording Resolution

6K 5952×3140
4K 4096×2160
2K 2048×1080

Maximum Frame Rate (PAL)

4K XF-AVC YCC 4:2:2 10-bit 50 fps
4K ProRes YCC 4:2:2 10-bit 25 fps
UHD XF-AVC YCC 4:2:2 10-bit 50 fps
UHD ProRes YCC 4:2:2 10-bit 50 fps
2K XF-AVC RGB 4:4:4:4 12-bit 50 fps
2K XF-AVC RGB 4:4:4:4 10-bit 50 fps
2K XF-AVC YCC 4:2:2 10-bit 100 fps
2K XF-AVC YCC 4:2:2 10-bit (sensor crop) 200 fps
2K XF-AVC YCC 4:2:0 8-bit (proxy) 25 fps
2K ProRes RGB 4:4:4:4 10-bit 50 fps
2K ProRos YCC 4:2:2 10-bit 50 fps



Media

Internal Recording CFast 2.0
Proxy Recording SD
Setup SD

Audio Recording Format

LPCM 2CH 24-bit 48-kHz

ISO

ISO Range 100-102,400

Internal ND Filters

Clear
IRND 0.6 (2 Stops)
IRND 1.2 (4 Stops)
IRND 1.8 (6 Stops)
IRND 2.4 (8 Stops with Extended ND)
IRND 3.0 (10 Stops with Extended ND)

Batteries

V-Lock

Inputs

1x BNC (Genlock)

1x BNC (Timecode I/O)

1x Ethernet (I/O)

1x 2.5mm Terminal (Remote Control)

2x XLR 3-pin (Audio)

1x 3.5mm Mini-Jack (Audio)

1x XLR 4-pin (Power)

Outputs

2x BNC (Monitor)

4x BNC (SDI)

1x HDMI

1x 3.5mm Mini-Jack (Headphones)

1x D-Tap

1x Lemo 2-pin (DC 12V Power)

1x Lemo 3-pin (DC 24V Power)

Weight

3.4 kgs
