Blackmagic Hyperdeck Studio Pro 2
Take a compact broadcast-quality record/playback deck with you on location, in the studio, or built into a rack with the Blackmagic Design HyperDeck Studio HD Mini. The 1 RU tall recorder is 1/3 of a rack wide and powers from 100 to 240 VAC, or via an optional 12 VDC power supply for portability. Featuring one 3G-SDI input, one each HDMI and 3G-SDI output, and a USB Type-C webcam output, the recorder is flexible, enabling you to input, record, and output/stream simultaneously. Supporting both reference and timecode in/out, this unit fits perfectly into a broadcast environment, and you can use one recorder to create an ISO recording of each camera with perfect sync for live and post-production work.
- Video Quality & Standards: Supports SD, HD up to 1080p60, and Ultra HD up to 2160p30. It records in 10-bit 4:2:2 uncompressed or compressed formats.
- Media & Storage: Features dual 2.5″ SSD slots for continuous recording; when one disk is full, it automatically switches to the next without dropping frames.
- Supported Codecs: Records to industry-standard formats including Apple ProRes (HQ, 422, LT, Proxy), Avid DNxHD, and uncompressed QuickTime.
I/O
| Connection Type | Port Description |
|---|---|
| Video Input | 1 x 6G-SDI, 1 x HDMI (Type A), 1 x Component (Y, B-Y, R-Y) |
| Video Output | 4 x 6G-SDI (Single or Quad Link), 1 x HDMI (Type A), 1 x Component (Y, B-Y, R-Y) |
| Digital Audio | 16-ch embedded (SDI), 8-ch embedded (HDMI) |
| Analogue Audio | 2 x XLR (Balanced In/Out), 2 x RCA (Unbalanced In) |
| Sync/Timecode | 1 x BNC Reference In (Black Burst/Tri-Sync), 1 x XLR Timecode In, 1 x XLR Timecode Out |
| Data/Control | 1 x Thunderbolt (Computer capture), 1 x USB 2.0 (Setup/Updates), 1 x Ethernet (RJ45), 1 x RS-422 (Deck control) |
| Power | 1 x Internal 100-240V AC (IEC C14 inlet) |
Video Format
| Format | Frame Rates |
|---|---|
| SD | 525i59.94 NTSC, 625i50 PAL |
| HD (720p) | 720p50, 720p59.94, 720p60 |
| HD (1080i) | 1080i50, 1080i59.94, 1080i60 |
| HD (1080p) | 1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60 |
| HD (1080PsF) | 1080PsF23.98, 24, 25, 29.97, 30 |
| Ultra HD 4K | 2160p23.98, 24, 25, 29.97, 30 |
